Design
Vehicle connection: Type 2 cable with plug
Built-in display: No
Cable length: 5 m
Housing colour: White
Recommended height (max): 2000 m
LED indicators: Yes
RFID reader: Yes
Housing material: Plastic
Power LED: Yes
Mounting style: Wall mount
Features
Counter : Modbus
Remotely operated: Yes
Monitoring of leakage current: Y
Communication protocol: OCPP1.6
Plug and Play: Yes
Ports & interfaces
Ethernet : Yes
Wi-Fi: Yes
Bluetooth: Yes
Power
Maximum output current : 16 A
Adjustable power: Yes
Input current: 16 A
Nominal frequency: 50 - 60 Hz
Number of phases: 3
Output voltage: 320 - 480 V
Input voltage: 380 - 420 V
Power: 11000 W
Safety warning
Hazard pictogram(s): GHS04: Compressed gas
Warnings: Do not use the unit in a damp or wet environment to avoid the risk of electric shock.
Hazard pictogram(s): GHS05: Corrosive
Security
RFID: Y
Grounding system supported: TN
Surge protection: Yes
International Protection (IP) code: IP54
Overvoltage category: III
Overcurrent protection: Yes
Degree of protection IK: IK08
Grounding system supported: TT
Overvoltage protection: Y
Weight & dimensions
Depth: 110 mm
Weight: 4.1 kg
Width: 195 mm
Height: 320 mm
