Features
Random read (4KB): 94000 IOPS
TBW rating: 7008
H/W PLP function: Yes
Read latency: 200 µs
Hardware encryption: No
Mean time between failures (MTBF): 2000000 h
Memory type: 3D TLC NAND
Write speed: 530 MB/s
Data transfer rate: 6 Gbit/s
SSD capacity: 3.84 TB
Interface: Serial ATA III
Hot-Plug support: Yes
Random write (4KB): 59000 IOPS
Use conditions: Server/Enterprise
Read speed: 560 MB/s
Target workload: Mixed Use (MU)
Write latency: 30 µs
SSD form factor: 2.5"
Component for: Server/workstation
Logistics data
Products per master (outer) case: 10 pc(s)
Master (outer) case length: 203.2 mm
Master (outer) case gross weight: 1.01 kg
Master (outer) case height: 69.8 mm
Master (outer) case width: 135.9 mm
Operational conditions
Operating temperature (T-T): 0 - 70 °C
Operating vibration: 2.17 G
Non-operating vibration: 20 G
Storage temperature (T-T): -40 - 85 °C
Packaging data
Package depth: 9.14 mm
Package height: 184.2 mm
Package width: 129.5 mm
Package weight: 93.2 g
Power
Power consumption (write): 3.6 W
Power consumption (average): 1.45 W
Power consumption (idle): 1.3 W
Power consumption (read): 1.6 W
Safety warning
Warnings: Protect from moisture and extreme temperatures.
Warnings: Do not open the appliance casing, risk of damage.
Weight & dimensions
Height: 7 mm
Weight: 71 g
Depth: 100.1 mm
Width: 69.8 mm
