Features
- Super-Fast 1.8 Gbps Wi-Fi - Enjoy smooth 4K streaming and downloading with super-fast Wi-Fi speeds of 1.8 Gbps
- Connect More Devices - Communicates with more devices using OFDMA while simultaneously reducing lag
- Broader Coverage - Improved algorithm, beamforming, and high-performance antennas enhance the Wi-Fi coverage performance
- Next-Gen Platform - The Next-Gen High-Efficiency Chipset provides fast and stable Wi-Fi while saving power consumption
- Parental Controls - Enjoy the most versatile yet free parental controls features among all routers, including URL blocking, profile management, pausing, and more
- Works with Most ISPs - Compatible with most ISPs with extra L2TP/PPTP support. IPTV support works with your existing TV over the Internet contract
- OneMesh - Use with OneMesh extenders to get whole-home coverage and enjoy smooth roaming between signals
- Easy Setup - Set up your router in minutes with the powerful TP-Link Tether App
- Backward Compatible - Supports all previous 802.11 standards Wi-Fi devices

Specifications
WIRELESS
- Standards: Wi-Fi 6
* IEEE 802.11ax/ac/n/a 5 GHz
* IEEE 802.11ax/n/b/g 2.4 GHz
- WiFi Speeds: AX1800
* 5 GHz: 1201 Mbps (802.11ax)
* 2.4 GHz: 574 Mbps (802.11ax)
- WiFi Range:
* 3 Bedroom Houses: 4× Fixed High-Performance Antennas - Multiple antennas form a signal-boosting array to cover more directions and large areas
* Beamforming: Concentrates wireless signal strength towards clients to expand WiFi range
- WiFi Capacity:
* High: Dual-Band, Allocate devices to different bands for optimal performance
* OFDMA: Simultaneously communicates with multiple Wi-Fi 6 clients
* Airtime Fairness: Improves network efficiency by limiting excessive occupation
* 4 Streams: Connect your devices to more bandwidth
- Working Modes: Router Mode, Access Point Mode

HARDWARE
- Processor: Dual-Core CPU
- Ethernet Ports: 1× Gigabit WAN Port, 4× Gigabit LAN Ports
- Buttons: WPS/Wi-Fi Button, Power On/Off Button, LED On/Off Button, Reset Button
- Power: 12 V = 1 A
SECURITY
- WiFi Encryption: WPA, WPA2, WPA3, WPA/WPA2-Enterprise (802.1x)
- Network Security: SPI Firewall, Access Control, IP & MAC Binding, Application Layer Gateway
- Guest Network: 1× 5 GHz Guest Network, 1× 2.4 GHz Guest Network
- VPN Server: OpenVPN, PPTP

SOFTWARE
- Protocols: IPv4, IPv6
- OneMesh
* OneMesh Supported
* Without replacing your existing devices or buying a whole new WiFi ecosystem, OneMesh helps you create a more flexible network that covers your entire home with TP-Link OneMesh products
- Parental Controls: URL Filtering, Time Controls
- WAN Types: Dynamic IP, Static IP, PPPoE, PPTP, L2TP
- Quality of Service: QoS by Device
- Cloud Service: Auto Firmware Upgrade, OTA Firmware Upgrade, TP-Link ID, DDNS
- NAT Forwarding: Port Forwarding, Port Triggering, DMZ, UPnP
- IPTV: IGMP Proxy, IGMP Snooping, Bridge, Tag VLAN
- DHCP: Address Reservation, DHCP Client List, Server
- DDNS: TP-Link, NO-IP, DynDNS
- Management: Tether App, Webpage

PHYSICAL
- Dimensions (W×D×H): 260.2×135.0×38.6 mm
- Package Contents: Wi-Fi Router Archer AX23, Power Adapter, RJ45 Ethernet Cable, Quick Installation Guide

OTHER
- System Requirements: Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser
* Cable or DSL Modem (if needed)
* Subscription with an internet service provider (for internet access)
- Certifications: FCC, CE, RoHS
- Environment:
* Operating Temperature: 0C to 40C (32F to 104F)
* Storage Temperature: -40C to 70C (-40F to 158F)
* Operating Humidity: 10% - 90% non-condensing
* Storage Humidity: 5% - 90% non-condensing

TEST DATA
- WiFi Transmission Power:
* CE: <20dBm (2.4 GHz), <23dBm (5.15 GHz - 5.25 GHz)
* FCC:: <30dBm (2.4 GHz & 5.15 GHz - 5.825 GHz)
- WiFi Reception Sensitivity:
* 5G:
11a 6Mbps: -96dbm
11a 54Mbps:-75dbm
11ac VHT20_MCS0: -95dbm
11ac VHT20_MCS8: -71dbm
11ac VHT40_MCS0: -92dbm
11ac VHT40_MCS9: -66dbm
11ac VHT80_MCS0: -89dbm
11ac VHT80_MCS9:-62dbm
11ax HE20_MCS0:-95dbm
11ax HE20_MCS11: -64dbm
11ax HE40_MCS0: -92dbm
11ax HE40_MCS11: -60dbm
11ax HE80_MCS0: -89dbm
11ax HE80_MCS11:-59dbm
* 2.4G:
11g 6Mbps:-96dbm
11g 54Mbps:-75dbm
11n HT20_MCS0:-95dbm
11n HT20_MCS7:-75dbm
11n HT40_MCS0:-92dbm
11n HT40_MCS7: -72dbm
11ac VHT20_MCS0:-95dbm
11ac VHT20_MCS8:-72dbm
11ac VHT40_MCS0:-92dbm
11ac VHT40_MCS9: -67dbm
11ax HE20_MCS0:-95dbm
11ax HE20_MCS11: -65dbm
11ax HE40_MCS0: -92dbm
11ax HE40_MCS11: -62dbm
